The 21.5-inch 1920×1080 30-pin LVDS TFT LCD module is a Full HD display solution designed for equipment manufacturers, system integrators and professional display applications that require a large-format TFT LCD with stable LVDS connectivity, 500 cd/m² brightness and a practical 16:9 viewing format. With an active area of 476.64 × 268.11 mm and a slim 11.25 mm profile, this module provides a balance between display area, image clarity and integration flexibility.
The model DBT215DHN30L050A uses a 30-pin LVDS interface and delivers 1920 × 1080 resolution with 16.7 million display colors. Its 500 cd/m² typical brightness makes it suitable for many indoor professional environments, including industrial control equipment, embedded systems, desktop monitors, retail equipment and information terminals. The module is specified for an operating temperature range of 0°C to +50°C and a storage temperature range of -20°C to +60°C.
For OEM and ODM projects, the LCD panel can also serve as the foundation for a more complete display assembly, including customized touch panel, cover glass, cable, controller board and mechanical integration according to project requirements.
The 21.5-inch screen size provides substantially more visual workspace than small embedded displays while maintaining the widely adopted 16:9 aspect ratio. The 1920 × 1080 Full HD resolution provides sufficient pixel density for user interfaces, monitoring dashboards, equipment parameters, diagrams, menus and multimedia content.
For industrial equipment designers, the large active display area of 476.64 × 268.11 mm provides enough space to present multiple operating parameters simultaneously. This can help reduce the need for frequent page switching in human-machine interface applications.
The module uses a 30-pin LVDS interface, making it appropriate for systems designed around LVDS-compatible display controllers and embedded computing platforms.
LVDS is widely used in professional display equipment because it provides a practical high-speed differential signaling method between a display controller and TFT LCD panel. For an existing system that already uses a compatible LVDS output, selecting a 30-pin LVDS panel can simplify display integration.
However, engineers should verify the complete interface definition before replacing an existing LCD. Pin assignment, signal mapping, power requirements, timing parameters, backlight control and connector orientation should all be checked against the controller board.
With a typical brightness specification of 500 cd/m², this display offers higher brightness than many conventional standard indoor LCD panels.
This makes the module particularly suitable for professional indoor environments where ambient lighting may be stronger than that of a typical office, including production facilities, control rooms, commercial equipment and public-facing terminals.
For direct sunlight or outdoor applications, however, 500 cd/m² should not automatically be considered sunlight-readable. Outdoor visibility depends on more than panel brightness, including optical bonding, surface treatment, ambient light, enclosure design and reflection control. For projects requiring direct-sunlight readability, Aptus Display can evaluate higher-brightness alternatives.
The active display area measures 476.64 × 268.11 mm, while the overall module dimensions are approximately 496 × 293 × 11.25 mm.
The relatively slim profile allows system designers to consider the module for applications where enclosure depth is limited. Mechanical engineers should nevertheless reserve sufficient space for the display connector, cable routing, controller electronics and thermal management.
The product specification lists a viewing angle of 85°/85°/85°/85° under CR ≥ 10, providing useful visibility when users are not directly positioned in front of the panel.
This characteristic is valuable for control panels, monitoring systems, kiosks and equipment interfaces where multiple operators may view the same screen from different positions.
| Parameter | Specification |
|---|---|
| Product Type | TFT LCD Module |
| Model | DBT215DHN30L050A |
| Display Size | 21.5 inches |
| Resolution | 1920 × 1080 pixels |
| Resolution Type | Full HD |
| Aspect Ratio | 16:9 |
| Active Area | 476.64 × 268.11 mm |
| Outline Dimension | 496 × 293 × 11.25 mm |
| Pixel Pitch | 0.24825 × 0.24825 mm |
| Pixel Arrangement | RGB Vertical Stripe |
| Display Colors | 16.7M / 8-bit |
| Display Mode | Normally White |
| Viewing Angle | 85° / 85° / 85° / 85° |
| Contrast Criterion | CR ≥ 10 |
| Response Time | 20 ms |
| Interface | 30-Pin LVDS |
| Brightness | 500 cd/m² typical |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +60°C |
The specifications above are based on the product information published for model DBT215DHN30L050A. Engineering teams should request the latest datasheet and interface drawings from Aptus Display before production integration because detailed electrical and mechanical parameters should be confirmed for each project.
The 21.5-inch Full HD LCD module is suitable for industrial control interfaces where operators need to view machine status, production parameters, alarms, process diagrams and system information.
The large screen area allows more information to be displayed simultaneously than smaller 7-inch, 10.1-inch or 12.1-inch industrial panels. This can be useful for factory automation equipment, production monitoring systems, process control equipment and operator interfaces.
For OEMs developing embedded equipment, the module can be integrated with an appropriate controller board and computing platform.
Potential applications include equipment terminals, monitoring systems, industrial computers, automation equipment and professional information systems. The 30-pin LVDS interface provides a straightforward starting point for systems already designed around LVDS display output.
The 21.5-inch Full HD format is also appropriate for professional desktop display applications.
The 1920 × 1080 resolution provides a familiar desktop workspace, while the 500 cd/m² brightness can provide strong visibility in bright indoor working environments.
For custom monitor manufacturers, Aptus Display can support additional integration requirements such as controller boards, housing, cables and touch panel solutions depending on project specifications.
The display can be integrated into professional retail equipment, POS terminals, self-service kiosks and information terminals.
When the application requires touch interaction, a compatible capacitive touch panel can be considered as part of a customized display assembly. The final touch solution should be selected according to the cover glass, operating environment, glove requirements, moisture exposure and mechanical design.
Large-format Full HD LCD modules are useful for applications that require clear presentation of charts, status information, schedules, dashboards or user instructions.
Examples include equipment monitoring terminals, commercial information systems, access terminals and professional control interfaces.
Selecting an LCD module should not be based on screen size and resolution alone. Engineers should evaluate the complete system interface, environmental conditions, optical requirements, mechanical constraints and expected product lifecycle.
This 21.5-inch module offers several practical advantages:
Full HD resolution: 1920 × 1080 provides a widely supported resolution for professional interfaces.
Large display area: The 21.5-inch format provides sufficient space for detailed HMI and monitoring interfaces.
LVDS connectivity: The 30-pin LVDS interface is suitable for compatible embedded controller architectures.
500 cd/m² brightness: Provides enhanced visibility for many professional indoor environments.
Slim mechanical profile: The approximately 11.25 mm module thickness supports integration into relatively compact enclosures.
Professional customization potential: The module can be evaluated as part of a customized LCD display solution rather than being limited to a standard panel-only configuration.
Before ordering samples or beginning mass production, system designers should confirm several technical factors.
First, verify that the host controller supports the required 30-pin LVDS interface and that its signal mapping matches the selected panel.
Second, confirm the panel timing requirements and electrical specifications with the latest technical documentation. A connector with the same number of pins does not necessarily guarantee compatibility between two different LCD panels.
Third, evaluate the backlight power and control method. The controller or power architecture should be designed according to the actual panel requirements.
Fourth, check the mechanical envelope. The specified panel dimensions are approximately 496 × 293 × 11.25 mm, but the final equipment should also accommodate cables, connectors, mounting structures and thermal clearances.
Finally, evaluate the environmental conditions. The published operating temperature range is 0°C to +50°C, so applications outside this range should be reviewed with Aptus Display before selection.
Aptus Display provides more than standard TFT LCD panels. According to the company's product information, its services include display customization, engineering support, prototyping, technical integration guidance, quality assurance, global supply and after-sales support.
For OEM and ODM customers, customization can be considered around the display itself or the complete display assembly.
Possible customization options may include:
Different brightness levels
Capacitive or resistive touch panels
Cover glass
Optical or adhesive bonding solutions
Customized cables
LVDS controller boards
Android or other embedded controller solutions
Customized housing and mechanical structures
Interface adaptation
Display assembly integration
This approach can reduce the engineering workload associated with sourcing separate LCD panels, touch panels, controller boards and accessories from different suppliers.
Aptus Display is a professional LCD display solution provider based in Shenzhen, China. The company focuses on TFT LCD modules, touch display solutions, display accessories and customized display integration.
The company states that it has experience in LCD module development and manufacturing, with services covering customization, engineering support, quality assurance and global supply. Its customer base includes markets in Europe, North America and Asia.
For B2B customers, the value of working with a display solution supplier extends beyond simply purchasing an LCD panel. Display compatibility, sample validation, touch integration, controller matching, mechanical design and long-term supply planning can all affect the success of a product development project.
Aptus Display therefore supports customers from product selection and sampling through technical integration and production supply.
Yes. The DBT215DHN30L050A provides 1920 × 1080 Full HD resolution, making it suitable for professional interfaces, monitoring systems and embedded display applications.
This model uses a 30-pin LVDS interface. Engineers should confirm the exact pin definition, timing and electrical requirements with Aptus Display before connecting it to a controller board.
The specified typical brightness is 500 cd/m². This is suitable for many professional indoor applications and bright indoor environments. For direct outdoor sunlight, a higher-brightness solution may be more appropriate.
Yes. Aptus Display provides customized display integration services, including touch integration. A capacitive or resistive touch panel can be evaluated depending on the application and mechanical requirements.
The published operating temperature range is 0°C to +50°C, while the storage temperature range is -20°C to +60°C. Applications requiring wider temperature performance should be discussed with Aptus Display before purchasing.
Yes. Aptus Display's product page provides a request-for-quote/sample route, and its listed services include prototyping and sample support. Customers should provide their application, required quantity and technical requirements when requesting a sample.
If you are developing an industrial control panel, embedded terminal, professional monitor, kiosk, retail system or other equipment requiring a 21.5-inch 1920×1080 LVDS TFT LCD, the DBT215DHN30L050A provides a practical Full HD display platform with 500 cd/m² brightness and a 30-pin LVDS interface.
For engineering evaluation, OEM projects and volume procurement, contact Aptus Display with your required display size, resolution, interface, brightness, quantity and application environment.
