►Size : 7.5 inch
►Resolution :800*800 dots
►Active Area : 135.36*135.36mm
►Interface :40PIN MIPI
►Touch Panel : CTP
►Brightness (cd/m²): 850
7.5-inch 800×800 high brightness square LCD module with capacitive touch panel and 40-pin MIPI interface. Ideal for flight simulators, industrial control panels, and embedded devices requiring reliable, sunlight-readable, and responsive touch displays. Contact Aptus Display for datasheets and pricing.
Precision Touch | Engineered for Flight Simulators & Industrial Applications
The 7.5-inch 800×800 square LCD module with capacitive touch panel (CTP) from Aptus Display is designed to provide outstanding visual clarity and responsive touch experience in a compact square format. With 1000 nits brightness, a 40-pin MIPI interface, and a highly sensitive capacitive touch panel, this display module delivers reliable performance for professional applications such as flight simulators, industrial control systems, and embedded smart devices.
The square aspect ratio fits perfectly in modern cockpit instrument panels and industrial dashboards, allowing precise visual representation of instruments and interactive controls.
Ensures visibility in bright indoor environments and direct sunlight.
✋ Capacitive Touch Panel (CTP)
Provides accurate and smooth touch input for enhanced user interaction.
📐 800×800 Resolution
High pixel density offers clear, detailed visuals suited for gauges and controls.
🔌 40-Pin MIPI Interface
Fast, efficient signal transmission compatible with embedded platforms.
👁️ Wide Viewing Angles
Consistent color and clarity from all directions.
🧊 Wide Operating Temperature
Stable operation between -20°C and +70°C.
🔋 Long Backlight Lifetime
Over 30,000 hours of continuous use.
| Specification | Details |
|---|---|
| Display Size | 7.5 inches (Square Format) |
| Resolution | 800 × 800 pixels |
| Brightness | 1000 cd/m² |
| Touch Panel | Capacitive Touch Panel (CTP) |
| Interface | 40-pin MIPI |
| Display Type | TFT LCD |
| Viewing Angle | Wide (all directions) |
| Operating Temperature | -20°C to +70°C |
| Backlight Lifetime | ≥30,000 hours |
| Active Area | 127.008 × 127.008 mm |
The square shape replicates classic cockpit gauges, and the integrated touch enables interactive control panels for realistic simulation experiences. High brightness ensures clear visibility under varied lighting.
Engineered to support long-term, 24/7 operation, this module combines a durable capacitive touch panel with a robust LCD backlight and wide temperature tolerance. The 40-pin MIPI interface ensures efficient, stable data transfer compatible with ARM and other embedded platforms.
The square format offers flexible design options, making it easier to integrate into compact or modular instrument layouts.
Serving OEMs and system integrators across Europe and North America, Aptus Display is dedicated to delivering high-quality LCD modules that meet stringent industry standards. We focus on:
Reliable product quality and consistent supply
Technical support during development and integration
Efficient logistics and on-time delivery
Custom solutions and volume production support
Every display undergoes rigorous testing for optical, electrical, and mechanical stability before shipment.
If you’re developing a project that requires a high-brightness, capacitive touch-enabled square LCD display, our 7.5-inch 800×800 module is ready to meet your needs.
📧 Contact our sales or technical team today for datasheets, quotations, or samples. We typically respond within one business day and provide full support for your integration process.
