The 17.3 inch 1920×768 30PIN LVDS 500nits CTP LCD Module is a high-performance wide-format TFT LCD display designed for commercial display systems, interactive terminals, and customized embedded display applications.
Developed with a 1920(H) × 768(V) pixel resolution, this LCD module delivers a wide viewing area, sharp image details, and excellent color performance. The integrated capacitive touch panel (CTP) provides smooth and responsive touch interaction, making it suitable for modern human-machine interfaces and self-service display solutions.
With a 500 nits brightness level, wide viewing angle performance, and LVDS interface compatibility, this 17.3-inch LCD module provides a reliable display solution for applications requiring clear visibility, stable operation, and easy system integration.
The module features a 17.3-inch diagonal active display area with a resolution of 1920 × 768 pixels, providing a wide horizontal viewing format that is ideal for applications requiring more information display space.
The wide aspect ratio design enables efficient presentation of menus, graphics, advertisements, dashboards, and interactive content while maintaining a compact installation footprint.
The LCD panel adopts an RGB vertical stripe pixel arrangement and supports 16.7 million colors with real 8-bit color depth, delivering smooth color transitions and detailed image reproduction.
With a typical brightness of 500 nits, this LCD module provides enhanced visibility compared with standard consumer displays.
The higher brightness output helps maintain image clarity in commercial environments with ambient lighting, including retail spaces, public terminals, and indoor information displays.
The display also features surface treatment combining:
This surface enhancement reduces unwanted reflections and improves viewing comfort during extended operation.
The 17.3-inch LCD module integrates a capacitive touch panel, providing accurate and responsive touch interaction.
The CTP solution supports intuitive operation for interactive applications, allowing users to directly control menus, select options, and interact with digital content.
Typical advantages include:
The touch-enabled design makes this module suitable for commercial interactive equipment and customized HMI solutions.
| Parameter | Specification |
|---|---|
| Product Type | 17.3 Inch TFT LCD Module with CTP |
| Model Number | DBC173BEC30L050A |
| Display Size | 17.3 inch |
| Resolution | 1920 × 768 pixels |
| LCD Type | TFT Active Matrix LCD |
| Display Mode | Normally Black |
| Color Depth | 8-bit |
| Colors | 16.7M Colors |
| Pixel Arrangement | RGB Vertical Stripe |
| Interface | LVDS |
| Connector | 30 PIN LVDS |
| Brightness | 500 nits |
| Contrast Ratio | 1000:1 Typical |
| Viewing Angle | 80° minimum (H/V) |
| Response Time | 14ms Typical |
| Surface Treatment | AG + AF + AR |
| Touch Type | Capacitive Touch Panel |
| Operating Temperature | 0℃ ~ +50℃ |
| Storage Temperature | -20℃ ~ +60℃ |
| Dimension | 435(H) × 190(V) × 24.05(D) mm |
This LCD module uses a 30-pin LVDS interface, providing a stable high-speed digital connection between the display panel and the host system.
LVDS technology is widely used in commercial and industrial display systems because of its advantages:
The module supports LVDS input with 2 pixels per clock and operates in DE (Data Enable) only mode, simplifying display controller configuration.
The 17.3-inch 1920×768 LVDS CTP LCD module is designed for applications requiring wide-format display performance and interactive functionality.
The wide resolution and high brightness make it suitable for:
The integrated touch panel allows the module to be used as an intuitive interface for:
The compact wide-format structure supports flexible installation orientations, including:
Aptus provides professional LCD customization services based on customer requirements, including:
Our engineering team helps customers integrate LCD modules into complete display products efficiently.
For OEM and ODM projects, Aptus supports the complete development process:
This approach helps customers reduce development time and improve product reliability.
This LCD module uses a 30-pin LVDS interface, designed for stable connection with compatible LCD controller boards and embedded systems.
Yes. The module integrates a capacitive touch panel (CTP), enabling interactive operation for commercial and embedded applications.
Yes. The module is designed for commercial digital displays, control terminals, and interactive display systems requiring reliable image quality and touch operation.
The LCD module provides 500 nits typical brightness, helping improve visibility in environments with normal ambient lighting.
Yes. Aptus supports customization services including touch solutions, cover glass design, driver boards, cables, and mechanical integration according to customer requirements.
The 17.3 Inch 1920×768 30PIN LVDS 500nits CTP LCD Module combines wide-format resolution, high brightness, LVDS compatibility, and integrated capacitive touch functionality into a compact commercial display solution.
With reliable TFT LCD technology, flexible customization options, and professional engineering support, this module is an ideal choice for companies developing digital signage, interactive terminals, and customized display equipment.
