Wide Temperature Solution for Harsh Environments (-40°C to +85°C)
This 7-inch TFT LCD module is engineered for industrial and embedded applications that require stable performance under extreme environmental conditions. With an extended operating temperature range of -40°C to +85°C, it ensures reliable functionality in both cold and high-temperature environments.
Featuring an LVDS 20-pin interface and IPS viewing technology, the display delivers consistent image quality, stable signal transmission, and excellent visibility across a wide range of applications.
This display module is suitable for:
Industrial control systems (HMI)
Automotive display terminals
Outdoor kiosks and smart terminals
Agricultural and heavy-duty equipment
Marine and cold-region devices
Embedded control panels
Extended temperature range (-40°C to +85°C), suitable for harsh environments
High brightness of 500 nits for clear visibility in bright conditions
LVDS 20-pin interface for stable signal transmission
IPS wide viewing angle for consistent display performance
Long lifespan with industrial-grade reliability
Support for customization including touch panel, custom GG5 cover glass, and optical bonding
| Item | Specification |
|---|---|
| Model Number | DBT070AVN20L050A |
| Screen Size | 7.0 inch |
| Resolution | 800 × 480 (WVGA) |
| Display Type | TFT LCD, Normally White |
| Viewing Angle | IPS, 80/80/80/80 |
| Interface | LVDS, 20-pin |
| Brightness | 500 cd/m² |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +95°C |
| Active Area | 152.4 × 91.44 mm |
| Outline Dimensions | 165 × 104 × ~5 mm |
| Pixel Pitch | 0.1905 × 0.1905 mm |
| LED Lifetime | ≥ 50,000 hours |
| Surface Treatment | Anti-glare, Hard coating |
This module is designed for compatibility with panels such as G070Y2-L01. It can be used in systems requiring a 7-inch display, 800×480 resolution, and LVDS interface, while maintaining industrial-grade performance and long-term supply stability.
We support flexible customization based on project requirements:
Capacitive (PCAP) or resistive touch panel
Custom GG5 cover glass
Optical bonding
Brightness adjustment
FPC and connector customization
Driver board support (HDMI / RGB / LVDS)
Q1: Can this display operate in extremely cold environments?
Yes, it is designed to operate within a temperature range of -40°C to +85°C, making it suitable for cold-region and outdoor applications.
Q2: Is it suitable for automotive applications?
Yes, the wide temperature range and stable performance make it suitable for automotive systems.
Q3: Can it support HDMI input?
Yes, with an external controller board, HDMI input can be supported.
Q4: Do you provide customization services?
Yes, we support full customization including touch panels, cover glass, and interface modifications.
