49" UHD curved gaming TFT-LCD module DC490R15L51V50A delivers true 3840×2160 4K resolution, R1500 curvature, 550 nits brightness, and excellent color uniformity with zero mura. Flagship 49-inch module for ultimate immersive gaming monitors and large custom builds. V-by-One 8-lane, IPS wide angle.
Flagship 4K Immersion with Zero Mura – The Largest Curved Gaming Display in the Series
Step into the next dimension of gaming with the DC490R15L51V50A, the flagship 49-inch UHD curved TFT-LCD module designed for builders who refuse to compromise on size or quality. This massive panel features true 3840×2160 4K resolution, a deep R1500 curvature, and factory-calibrated excellent color uniformity with zero visible mura — delivering perfectly consistent brightness and color across every inch of the enormous curved screen.
Engineered as a complete open-cell module with integrated side-entry LED backlight, it offers vibrant 550 nits typical brightness that ensures clear, vivid visuals in any gaming environment. The IPS panel with anti-glare treatment and full 178° viewing angle guarantees flawless performance whether you’re alone in an intense session or sharing the screen with friends. The reinforced 1094.52 mm outline and 27 mm thickness provide exceptional structural rigidity, making it ideal for large custom enclosures, sim-racing cockpits, or professional multi-monitor walls.
This 49-inch flagship module is the ultimate foundation for building the largest and most immersive curved gaming monitors available.
| Parameter | Specification | Unit / Advantage |
|---|---|---|
| Screen Diagonal | 48.5" (49" class) | R1500 Curvature – flagship size |
| Resolution | 3840 × 2160 UHD | True 4K on massive curve |
| Active Area | 1051.24 (H) × 604 (V) | mm |
| Pixel Pitch | 0.27963 × 0.27963 | mm |
| Contrast Ratio | 1100 : 1 (Typ.) | Deep gaming blacks |
| Brightness (White) | 550 (Typ.) | cd/m² – vibrant & clear |
| Color Depth | 1.07 Billion (10-bit) | Lifelike AAA colors |
| Response Time (G to G BW) | 9 ms (Typ.) | Smooth motion |
| Surface Treatment | Anti-Glare, Haze 3%, Hard Coating 2H | Low reflection |
| Viewing Angle (CR>10) | 178° all directions | IPS wide angle |
| Interface | V-by-One 8 Lane | High-bandwidth 4K |
| Power Consumption (Panel) | 88.3 W (Typ.) | Premium performance |
| Operating Temperature | 0 °C to +50 °C | Reliable gaming range |
| Storage Temperature | -20 °C to +60 °C | Worldwide shipping |
| Outline Dimension | 1094.52 (H) × 642.8 (V) × 27 (D) | mm – reinforced flagship build |
| Weight | 10.5 kg (Typ.) | Solid premium feel |
| Compliance | RoHS | Eco-friendly |
All values measured at 25 °C with standard test patterns. Supports 47–63 Hz (60 Hz typical) for smooth 4K gaming.
At 49 inches with R1500 curvature, the DC490R15L51V50A creates an unprecedented level of presence. The entire game world wraps around your vision in stunning 4K detail. Zero mura ensures consistent brightness and color across the entire curve — critical for long competitive sessions where any imperfection breaks focus.
The 550 nits brightness combined with anti-glare coating delivers vibrant, clear visuals in any gaming room. The V-by-One 8-lane interface guarantees stable, low-latency 4K signals, while the 10-bit color depth and 1100:1 contrast bring HDR games to life with cinematic depth. Reinforced construction makes it perfect for large custom builds.
The precise mechanical design and 27 mm thickness fit seamlessly into curved chassis or professional installations.
The DC490R15L51V50A has passed full optical, environmental, and long-term reliability testing. Precise power sequencing and robust backlight design ensure years of flawless performance in demanding gaming environments.
Q: Is this suitable for 4K gaming at high frame rates? A: Yes! True 3840×2160 UHD resolution with fast 9 ms response time delivers smooth, tear-free gameplay at 60 Hz.
Q: Does it really have zero mura? A: Excellent color uniformity with strict factory calibration — zero visible mura across the entire massive curved screen.
Q: What makes the 49" flagship special? A: Largest active area (1051.24 × 604 mm) and deepest immersion at R1500 curvature for the ultimate wrap-around experience.
Q: What interface does it use? A: V-by-One 8 Lane — the professional standard for stable 4K curved gaming panels.
Q: Does it support HDR? A: Yes — 10-bit color depth, high contrast, and 7300K color temperature are fully HDR10 compatible.
The DC490R15L51V50A flagship UHD curved gaming module combines the largest screen size, true 4K resolution, R1500 curvature, zero-mura uniformity, and vibrant performance in one powerful package.
Contact APTUS Display today for:
Elevate your gaming experience to flagship level with this premium 49" UHD R1500 curved TFT-LCD module — built for total immersion.
