The 14-inch 1920×1080 LCD module with a 30-pin eDP interface is designed for commercial indoor applications requiring reliable visibility and stable operation. With an operating temperature range of -20°C to +65°C and a storage temperature range of -20°C to +70°C, this module supports embedded control panels, professional equipment displays, and indoor commercial systems that may experience moderate temperature variations.
Unlike standard commercial panels, this display is engineered for consistent brightness, clear visualization, and dependable performance in indoor environments where temperature fluctuations are possible. Its 600-nit brightness ensures readability even in brightly lit facilities, while the eDP interface provides high-speed, low-noise signal transmission for embedded controllers.
| Specification | Details |
|---|---|
| Display Size | 14 inches |
| Resolution | 1920 × 1080 |
| Interface | 30-pin eDP |
| Active Area | 309.12 × 173.76 mm |
| Pixel Pitch | 0.161 mm |
| Display Colors | 16.7M (8-bit) |
| Brightness | 600 nits |
| Contrast Ratio | 1000:1 |
| Response Time | 25 ms (typical) |
| Viewing Angle | 85/85/85/85 (L/R/U/D) |
| Backlight | LED backlight |
| Operating Temperature | -20°C to +65°C |
| Storage Temperature | -20°C to +70°C |
| Power Supply | Standard eDP panel voltage |
Positioning the technical specifications at the top allows engineers and decision-makers to quickly identify critical parameters before exploring additional content about functionality and applications.
The 1920×1080 resolution is optimized for commercial embedded applications, offering a balance between clarity and system efficiency. It enables:
Clear text and icon display for professional interfaces
Smooth rendering of dashboards and control elements
Efficient performance on embedded processors
Predictable and reliable operation in controlled indoor environments
This practical resolution ensures operators and embedded system users can monitor and interact with equipment effectively.
The module's 30-pin eDP interface provides:
High-speed data transmission for smooth visual output
Reduced electromagnetic interference (EMI)
Simplified cabling and system integration
Compatibility with modern embedded processors and SoC architectures
This interface ensures reliable integration in commercial embedded systems.
With a 600-nit backlight, the display maintains clear readability in indoor commercial environments with bright ambient lighting. Optical features include:
Consistent contrast for accurate visualization of interface elements
Wide viewing angles for operator accessibility
Uniform brightness across the display area
These features make it suitable for embedded commercial applications where readability and stability are critical.
The -20°C to +65°C operating range allows the module to function reliably in indoor commercial environments with moderate temperature variation. This flexibility ensures:
Reliable performance in environments where temperature may fluctuate
Extended operational capabilities for embedded systems running continuously
Consistent backlight and display performance across temperature ranges
The -20°C to +70°C storage range also ensures safe handling and storage without affecting long-term display integrity.
This 14-inch LCD module is designed for commercial indoor embedded applications, excluding automotive, medical, and consumer electronics. Typical use cases include:
Embedded control panels for commercial equipment
Professional commercial displays in indoor embedded systems
Monitoring and visualization panels for commercial environments
These applications emphasize reliability, clarity, and embedded integration in controlled indoor settings.
To ensure stable operation:
Secure installation prevents vibration or mechanical stress, supporting long-term stability.
Use a regulated power source to maintain backlight and display consistency.
Ensure proper eDP cabling and grounding for stable image output.
Even within -20°C to +65°C, adequate ventilation ensures consistent performance and LED backlight longevity.
Aptus Display applies rigorous quality control to ensure each LCD module meets professional standards:
Visual and pixel uniformity inspection
Electrical and interface testing
Brightness and contrast verification
Environmental reliability testing across the full temperature range
Long-term operational stability testing
These procedures guarantee stable performance for wide-temperature commercial embedded applications.
Aptus Display provides LCD modules and embedded display solutions for commercial applications, emphasizing reliable, integration-ready products. Our displays support indoor commercial environments and professional embedded systems requiring consistent performance and durability.
Our product portfolio includes compact to medium-sized panels optimized for long-term reliability, stable operation, and seamless integration in commercial embedded applications.
Tailoring interface options, brightness, mechanical dimensions, and optional touch integration for project-specific requirements.
Guidance for electrical integration, signal optimization, mechanical mounting, and performance tuning.
Customized display solutions from concept design to volume production aligned with specifications and timelines.
Stable product availability and lifecycle management for extended commercial deployment.
For the 14-inch 1920×1080 30-pin eDP 600nit LCD module, Aptus Display provides technical support, customization, and reliable supply for commercial indoor embedded applications.
